Square O Strap - 1'' CPVC, 11'' × 10'', w/ Strap
CPVC Preformed Copper & Valves
CPVC Stub Out Elbow
- • Do not allow CPVC portion of fitting to be heated.
- • Radius bend for better flow and less noise.
- • The CPVC resin used in this product has been tested, and is monitored on an ongoing basis, to assure its chemical compatibility with FlowGuard Gold®, BlazeMaster® and Corzan® piping systems and products made with TempRite® Technology.
- • Accepts sweat, push-fitting and compression stop valves.
- • Prop 65 WARNING
- • Square mounting strap is crimped to tube.
- • Type L copper tube - Combines elbow and cap in one quick, easy stub out fitting.
- • ASTM - D2846, CSA - B137.6, NSF/ANSI/CAN - 372
Product Information
| Item No | Description | Pkg | Min Qty | Case Qty | |
|---|---|---|---|---|---|
| Square O Strap | |||||
| B | 25 | 25 | |||
| ▶ | B | 10 | 10 | ||
| Connection 1 Size | 1 IN |
| Connection 1 Type | CPVC |
| Connection 2 Size | 1 IN |
| Connection 2 Type | Closed |
| Height | 11 IN |
| Length | 10 IN |
| Square Strap? | Yes |
| Type | Stub Out Elbow |
No finish installation documents available for this product.
